DriSeals
DriSeals attach to wood and FRP beams to close the gap between the packs and supports, preventing air leaks and reducing drift eliminator installation time. DriSeals are sized for a tight seal against support ties, allowing for oversized cut-outs in drift eliminator packs. Each corrosion-resistant, non-flammable PVC DriSeal includes nail tabs with pilot holes for quick and secure installation.
Benefits
Close the gap between drift eliminator packs & supports
Reduce drift eliminator installation time
Navigate Within Water & Air Management
Specifications
English
Metric
| Products | Description | Weight/100 Pcs lbs | Width inches | Length inches | Thickness inches | Accommodates Channel/column Size | Hole Size inches | Tie Spacing inches |
|---|---|---|---|---|---|---|---|---|
| Fiberglass 3 x 3 | 3 x 3" FRP column | 6 | 5.875 | 85.875 | 0.034 | 3 x 3 | N/A | N/A |
| Fiberglass C3.5-3.5" | 3.5 x 0.375" channel with 3.5" post | 14 | 10 | 8 | 0.034 | C3.5 | N/A | 3.5 |
| Fiberglass C4-3.5" | 4 x 0.25" channel with 3.5" post | 14 | 10 | 8 | 0.034 | C4 | N/A | 3.5 |
| Fiberglass C5.5-3.5" | 5.5 x 0.25" channel with 3.5" post | 17.5 | 10 | 10 | 0.034 | C5.5 | N/A | 3.5 |
| Fiberglass C6-3.5" | 6 x 0.25" channel with 3.5" post | 17.5 | 10 | 10 | 0.034 | C6 | N/A | 3.5 |
| Fiberglass C8-3.5" | 8 x 0.25" channel with 3.5" post | 24.3 | 11.25 | 12.375 | 0.034 | C8 | N/A | 3.5 |
| Fiberglass C3.5-3" | 3.5 x 0.375" channel with 3" post | 13.3 | 8 | 9.5 | 0.034 | C3.5 | N/A | 3 |
| Fiberglass C4-3" | 4 x 0.25" channel with 3" post | 14 | 10 | 8 | 0.034 | C4 | N/A | 3 |
| Fiberglass C6-3" | 6 x 0.25" channel with 3" post | 17.5 | 10 | 10 | 0.034 | C6 | N/A | 3 |
| Wood 2 x 4 | 2 x 4" dimensional lumber | 12.25 | 10 | 7 | 0.034 | N/A | 1.5 x 3.5 | 3.5 |
| Wood 2 x 6 | 2 x 6" dimensional lumber | 15.75 | 10 | 9 | 0.034 | N/A | 1.5 x 5.5 | N/A |
| Wood 4 x 4 | 4 x 4" dimensional lumber | 7.4 | 6.5 | 6.5 | 0.034 | N/A | 3.5 x 3.5 | N/A |
| Products | Description | Weight/100 Pcs kg | Width mm | Length mm | Thickness mm | Accommodates Channel/column Size | Hole Size mm | Tie Spacing mm |
|---|---|---|---|---|---|---|---|---|
| Fiberglass 3 x 3 | 3 x 3" FRP column | 2.72 | 149.23 | 149.23 | 0.864 | 3 x 3 | N/A | N/A |
| Fiberglass C3.5-3.5" | 3.5 x 0.375" channel with 3.5" post | 6.35 | 254 | 203.2 | 0.864 | C3.5 | N/A | 88.9 |
| Fiberglass C4-3.5" | 4 x 0.25" channel with 3.5" post | 6.35 | 254 | 203.2 | 0.864 | C4 | N/A | 88.9 |
| Fiberglass C5-3.5" | 5.5 x 0.25" channel with 3.5" post | 7.94 | 254 | 254 | 0.864 | C5.5 | N/A | 88.9 |
| Fiberglass C6-3.5" | 6 x 0.25" channel with 3.5" post | 7.94 | 254 | 254 | 0.864 | C6 | N/A | 88.9 |
| Fiberglass C8-3.5" | 8 x 0.25" channel with 3.5" post | 11.02 | 285.75 | 314.33 | 0.864 | C8 | N/A | 88.9 |
| Fiberglass C3.5-3" | 3.5 x 0.375" channel with 3" post | 6.03 | 20.3.2 | 241.3 | 0.864 | C3.5 | N/A | 76.2 |
| Fiberglass C4-3" | 4 x 0.25" channel with 3" post | 6.35 | 254 | 203.2 | 0.864 | C4 | N/A | 76.2 |
| Fiberglass C6-3" | 6 x 0.25" channel with 3" post | 7.94 | 254 | 254 | 0.864 | C6 | N/A | 76.2 |
| Wood 2 x 4 | 2 x 4" dimensional lumber | 5.56 | 254 | 177.8 | 0.864 | N/A | 38.1 x 88.9 | 88.9 |
| Wood 2 x 6 | 2 x 6" dimensional lumber | 7.14 | 254 | 228.6 | 0.864 | N/A | 38.1 x 139.7 | N/A |
| Wood 4 x 4 | 4 x 4" dimensional lumber | 3.36 | 165.1 | 165.1 | 0.864 | N/A | 88.9 x 88.9 | N/A |
